RFID Aviation Tags for Airlines Luggage Baggage Tracking

HUAYUAN airline baggage tags are optimized for the aviation industry - tracing and tracking bags.
HUAYUAN integrates a powerful design with IMPINJ MONZA 4QT, they provide the best of their kind and true global performance for RFID tag applications in this particular domain.
RFID baggage tags can help reduce the likelihood of lost luggage, provide enhanced security, increase baggage handling, efficiency, and improved on-time attendance, all of which greatly improve customer satisfaction.

Send email to us Download as PDF

Product Detail

Product Tags

HUAYUAN RFID Aviation tags is compliance IATA 1740 C standard, as the omini-direction antenna can be read range between 6 Meters to 8 Meters, covered global frequency from 860MHz to 960MHz (Reader gain: 20-30 db. in test in anechoic chamber by Tagformance Pro).

HUAYUAN is self-developed new arrival liner-less RFID Aviation Tag for airline tagging tracking:) The material of all alternative face stock compliance FSC Certification, all glue and materials composite environmental requirement. RFID airline Tags been proofed well printed by Barcode Printers like, IER, INTERMIC, SATO, Fujitsu. e.g.

The advantage of HUAYUAN RFID Aviation tagging:

1. Production capacity over billions of tags per year

2. State-of-art facility like Mühlbauer bonding, Bielomatik converting etc.

3. Most competitive price in huge project

Specifications of RFID aviation baggage tags

A.Technical data of RFID aviation baggage tags:

Item	RFID aviation tag
Protocol	EPC Class 1 Gen 2/ISO 18000-6C
Manufacture / IC	IMPINJ M4QT
EPC / TID /User Memory/Kill Pass	128 bits /48 bits /512 bits/32 bits
Size	54054mm, 50154mm or 399*51mm
Material	Art paper
Antenna	AL etching with thickness 0.03mm adhesive layer
Inlay structure	Etching AL 9 µm + PET 50 µm
Operating Frequency	860～960MHz
Operating Mode	Passive
IC Life	100,000 Programming cycles, 10Yrs data retention
ESD Voltage Immunity	Max.2000V Human being mode(HBM)
Read Range	Depend on RFID inlay and RFID reader antenna
RFID Tag craft services	Customer specific encoding of EPC, Customized printing of Logo, text, Barcode etc

B.Structure of RFID aviation tag:

structure-of-rfid-aviation-baggage-tag

How to choose the right inlay for your RFID aviation tag project?

Because baggage will have different directions during the check-in process, in order to make the tags readable in different directions and avoid missed reading,

Generally, omnidirectional inlay is the highly selected, for example: H47 inlay, H41 inlay, etc.
